Power Monitoring Equipment Rentals
Renting Power Monitoring Equipment from JM TEST Systems
JM Test Systems offers both power/energy loggers and Power quality Analyzers for rent from many major manufacturers. Fluke, AEMC, Megger, and Amprobe are our most popular options. These units are used to capture and log voltage, current, power and harmonics to deliver complete data for load studies, energy assessments, and voltage events. Our rental inventory includes Fluke 1736, 435-II and 1750. Along with the AEMC Pel-103, Amprobe DM-5 and Megger MPQ1000 which will cover you for any single or three phase test you need to perform. We also offer the Fluke 438-II that can provide not only analysis on power distribution systems but also can give information to evaluate a motors performance. Each of our rental units comes with software to allow you to view and create reports after completing your testing. If you’re unsure of which unit fits your testing needs see our comparison chart below between Power logger and Power Quality analyzers or Give us a call at 1-800-353-3411.
Power/Energy Loggers
Basic tools for discovering where energy savings are possible as well as what can be added to an existing service. Power loggers conduct energy and load studies and offer insight into electrical issues with detailed reports. A power logger is also ideal for validating voltage quality and finding power quality trends. Power recorders fall into this category, devices designed for long-term electrical studies that reveal hidden or sporadic electrical trends that only manifest over time.
Power Quality Analyzers
Power quality analyzers troubleshoot electrical issues. A power quality meter locates power quality faults and performs load studies, energy waste assessments, and quality compliance testing. Power quality analyzers display electrical diagnostic information live, offering the advantage of immediate access to data.
Common Names for this type of instrument:
- Power Quality Logger
- Power Quality Recorder
- Energy Logger
- Power Logger
Common names for this type of instrument
- Power Quality Meter
- Power Quality Monitor
- Power Analyzer
- Energy Analyzer
Understanding power quality, load studies, problems with voltage sags or swells or intermittent voltage disturbances. Simple voltage and current checks.
Applications
- Recurring problems like motors or transformers overheating, breakers tripping
- Power factor studies
- Flicker analysis
- Substation monitoring
- Motor troubleshooting and inrush testing
Key Measurements
- Energy & load studies
- Key power parameters (voltage, current, frequency)
- Energy consumption testing (what are you spending)
- Voltage events
- Harmonics
- Basic power quality analysis
Key Measurements
- Energy & load studies
- Key power parameters (voltage, current, frequency, transients)
- Energy consumption testing
- Voltage events
- Harmonics
- Advanced power quality analysis
- Locating, predicting, preventing & troubleshooting electrical issues
- Waste energy monetization
- Power waveform analysis
JM TEST RECOMMENDED PRODUCTS
AEMC PEL103
- Simple, Low Cost, Practical Datalogger for Load Study Applications.
- Measures multiple circuit types including Single Phase, Split Phase, Three Phase and DC Circuits.
- Power measurements: kVA, kW, kvar
- Energy measurements: kVAh, kWh(source, load) and kvarh
- Includes DataView® software for configuring, real-time display, analysis and report generation
- Data is recorded onto a removable SD card
- Satisfies monitoring requirements of NEC Code 220.87
- Records cost of energy usage
- Powered by the recorded circuit with optional input power cord eliminator
Fluke 1736
- Single & Three Phase Power Logger
- Measure all three phases and neutral with included four flexible current probes
- Capture dips, swells and inrush current
- More than 20 separate logging session can be stored on the instrument. They can even be viewed during logging sessions.
- Bright , color touch screen
- Includes Energy Analyze Plus application software to download and analyze every detail of energy consumption and power quality with automated reporting
JM TEST RECOMMENDED PRODUCTS
Fluke 1750
- Premium accuracy and measurement techniques: Guaranteed for all power quality parameters, with IEC 61000-4-30 Class A measurement systems
- Quick and reliable configuration: PDA wireless “front panel interface” provides a window into what the instrument is recording, even in awkward test locations
- Threshold-free setup: Apply thresholds after data is collected with Fluke Power Analyze Software
- Captures everything: Cross-channel and current triggering capture every measurement, on every channel, every time
- Intuitive PC software: Easily analyze data and generate reports Capture every measurement, every event, on every cycle, all the time with the Fluke 1750 Power Recorder
- Plug and play: Set up in minutes with self-identifying current probes and single-lead voltage connections
- No need to reconnect wires: Swap channels internally with the wireless PDA or PC when connections are not correct Measure every parameter: voltage and current on three phases, neutral, and ground • 5 MHz, 8000Vpk waveform capture: Get a detailed picture of even the shortest events
- Quickly retrieve data: With included SD memory card or via the 100BaseT high-speed Ethernet connection
Fluke 1770
- Make power quality investigations faster and easier.
- Automatic measurements, a simple user interface and setup, best-in-class specs, and a simplified reporting platform.
- fast transients up to 8 kV, harmonics up to 30 kHz, dips and swells, as well as voltage, current, and power measurements to describe your electrical system.
- 4 inputs, 3 phases and neutral referenced to PE (5 connectors)
- 1000 V CAT III / 600 V CAT IV
- 1000 V rms / 1000 V dc (1700 Vpk)
Fluke 435-II
- Energy loss calculator: Classic active and reactive power measurements, unbalance and harmonic power, are quantified to pinpoint true system energy losses in dollars
- Power inverter efficiency: Simultaneously measure AC output power and DC input power for power electronics systems using optional DC clamp.
- Waveform capture: 435 and 437 Series II models capture 50/60 cycles (50/60Hz) of each event that is detected in all modes, without set-up.
- Automatic Transient Mode: 435 and 437 Series II analyzers capture 200 kHz waveform data on all phases simultaneously up to 6 kV.
- Measure all three phases and neutral: With included four flexible current probes with enhanced thin flex designed to fit into the tightest places.
- View graphs and generate reports: With included analysis software.
- Battery life: Up to 8 hours operating time per charge on Li-ion battery pack.
Megger MPQ1000
- The Megger MPQ1000 Power Quality Analyzer is an advanced handheld 3-phase analyzer.
- Automatic CT recognition means never having the unit programmed for an incorrect range.
- CTs are powered by the unit so there is no need for additional connections or batteries.
- Connection verification ensures the unit is configured correctly and you get the data you need — no wasted recordings.
- On-board data analysis saves time by allowing an immediate examination of data before leaving the site.
- Multiple communication methods (USB, Ethernet, USB stick or SD card) allow for flexible and convenient operation.
- Removable SD card allows for large recording capabilities and simple memory expansion.
- The expanded 1000 V ac range allows for more application; no need for a second unit.
- 1000 V dc measurement allows testing and analysis of renewable applications dismissing the need for additional equipment.
- Smart configuration in the Megger PQ software for quick and easy setup.
- Phase angle stability measurement lets you easily find tricky phasing problems caused by multiple erratic sources.
- Timed waveform capture allows for the taking of PQ events and periodic waveforms at the same time. Easy intuitive menus allow for simple navigation and operation.
- Free software included means no license or dongle
Amprobe DM-5
- Simultaneously measures power, harmonics, waveform, power quality (voltage: 3-channel, current:4-channel)
- Measures single and three-phase power system with 10 selectable wiring connection settings
- Test parameters voltage, current, active/reactive/apparent power, PF and frequency all on one screen
- Quick start mode, wiring check and auto current sensor detection for quick, accurate measurements
- Automatic recording with memory for up to 1,000 parameters at user defined intervals
- Includes thin flex current sensor with user selectable input ranges of 300 A, 1000 A, or 3000 A
- Power quality events: Swell, Dip, Interruption, transients, Inrush current, and flicker
- Real-time remote monitoring on compatible PC and Android devices via Bluetooth communication
Fluke 438-II Power Quality and Motor Analyzer
- Measure key parameters on direct-on-line motors including torque, RPM, mechanical power and motor efficiency
- Perform dynamic motor analysis by plotting of motor de-rating factor against load according to NEMA guidelines
- Calculate mechanical power and efficiency without the need of mechanical sensors, just connect to the input conductors and you’re ready to go
- Measure electrical power parameters such as voltage, current, power, apparent power, power factor, harmonic distortion and unbalance to identify characteristics that impact motor efficiency
- Identify power quality issues such as dips, swells, transients, harmonics and unbalance
- PowerWave data technology captures fast RMS data, and shows half-cycle averages and waveforms to characterize electrical system dynamics (generator start-ups, UPS switching etc.)
- Waveform capture function captures 100/120 cycles (50/60 Hz) of each event detected event, in all modes, without set-up
- Automatic transient mode captures waveform data at 200 kS/s on all phases simultaneously up to 6 kV.
RENT POWER DATA LOGGERS & POWER ANALYZERS
JM Test has power analyzer, power data logger, and power quality analyzer rental units available. Local pickup and quick shipping options are available on most of our models. Buy, rent, or lease from various makes like AEMC, Amprobe, Fluke, Megger, and Powersight. Our rental inventory includes energy / power loggers, power quality analyzers, power quality meters, and power analyzer rental units. Choose a category below to start your search or browse through the pages of available units. If you have any questions, please submit a quote request or contact us today. Most rental units include the various accessories needed for the operation of the unit. Your final quote will outline each of the included items.
Showing 1–24 of 54 results
-
Rent Energy Logger
-
Power Logger Rental
-
Power Quality Analyzer Rentals
-
AEMC PEL 103 Power & Energy Logger (with display)
SKU: PEL103This product has multiple variants. The options may be chosen on the product page -
Fluke 1736 Power Logger
SKU: 1736 -
Fluke 435 Series II Power Quality Analyzer
SKU: 435 series II -
Fluke 1750 Three-Phase Power Quality Recorder
SKU: 1750 -
Megger MPQ1000 Handheld Power Quality Analyzer
SKU: MPQ1000 -
Amprobe DM-5 Power Quality Analyzer
SKU: DM-5 -
AEMC PowerPad Model 8335 with 193-24-BK AmpFlex Three-Phase Power Quality Analyzer
SKU: 8335 with 193-24-BK -
Fluke 1735 Power Logger – Obsolete
SKU: 1735 -
AEMC 3945 Three Phase Power Quality Analyzer – Discontinued
SKU: 3945 -
AEMC 8333 Three-Phase Power Quality Analyzer
-
AEMC 8336 Three-Phase Power Quality Analyzer
SKU: 8336 -
AEMC 8435 Three-Phase Power Quality Analyzer – Discontinued
SKU: 8435 -
AEMC 8435 w/AmpFlex Three-Phase Power Quality Analyzer
SKU: 8435 w/4 A196-24-BK -
AEMC 8436 Three-Phase Power Quality Analyzer
SKU: AEMC 8436 -
AEMC L101 Simple Logger® II Single Channel AC Current Logger
SKU: L101 -
AEMC L102 Simple Logger® II AC Current Logger
SKU: L102 -
AEMC L111 Simple Logger® II Single Channel AC Current Logger
SKU: L111 -
AEMC L205 Simple Logger® II AC Voltage Logger
SKU: L205 -
AEMC L215 Simple Logger® II AC Voltage Logger
-
AEMC L260 Simple Logger® II AC Voltage Logger
SKU: L260 -
AEMC L261 Simple Logger® II One Channel AC Voltage Logger
SKU: L261 -
AEMC L322 Simple Logger® II 4 to 20mA Two Channel Logger
SKU: L322 -
AEMC L410 Simple Logger® Single Channel DC Voltage Loggers
SKU: L410 -
AEMC L432 Simple Logger® II Two Channel DC Voltage Data Loggers
SKU: L432
