Choosing the Right Ground Resistance Tester

At JM Test, we understand the importance of selecting the right tool for the job, and that includes your ground resistance tester. Just like electrical and instrumentation needs vary across projects, so too do the testers best suited to tackle them.

Here at JM Test, we offer a wide range of ground resistance testers for purchase and rental – from compact, handheld models to feature-packed field instruments. Whether you need a simple and affordable solution for a quick ground check or a comprehensive testing solution for complex projects, we’ve got you covered.

In this article, our JM Test team dives into key questions to consider when selecting a ground resistance tester. By guiding you through these factors, we aim to help you choose the perfect instrument to meet your specific testing needs and ensure your project runs smoothly.

Our goal is to help guide you in choosing the instrument best suited to your specific application and requirements.

Q. Do you need to regularly test sites for soil resistivity?

If new grounding systems are in your project pipeline, then yes, you’ll need a 4-pole tester. Our testers range from basic models with manual calculations to advanced options with built-in resistivity functions for faster, error-free results.

Q. What type(s) of ground systems will you test?

Selecting the right ground resistance tester goes beyond just picking a tool.

Just like the electrical systems they protect, grounding systems come in all shapes and sizes. This is especially true when comparing industrial and residential applications. It’s key to ensure you have the right tool for the job and consider the scale and complexity of the grounding systems you’ll be testing.

Residential Grounding: Typically, residential grounding systems are relatively straightforward. They often consist of a single copper rod or grounding electrode driven into the earth near the building’s foundation and connected to the electrical service entrance panel. This grounding path safeguards residents from potential electrical shock in case of faults within the home’s wiring system

Industrial Grounding: Industrial facilities require a more robust approach to grounding due to the increased complexity of their electrical systems. These facilities often utilize intricate grounding grids – networks of interconnected electrodes, grounding rods, and grounding wires strategically buried throughout the site. This complex web ensures proper current dissipation in case of faults, protects personnel from electrical shock, and safeguards sensitive equipment. The scale and design of these grounding grids can vary greatly depending on factors like facility size, power requirements, and industry regulations. For instance, large-scale industrial plants or substations may have extensive grounding grids compared to smaller facilities.

By understanding the specific grounding system you’ll be testing, whether residential or industrial, you can choose a ground resistance tester with the appropriate features and capabilities. This ensures you get accurate measurements and efficient testing procedures tailored to the application.

Ensuring a proper ground connection is crucial for electrical safety in your home. A key part of this process is measuring the resistance of your house grounding rod. This resistance value tells you how effectively electricity can be channeled away from your house in case of a fault.

But how do you go about measuring this resistance?

The type of tester you need and the length of the test leads depend on whether your house is connected to the power line yet.

If your house is still under construction and not hooked up to electricity, a basic 3-pole ground resistance tester is a suitable choice. Some 4-pole testers can also be configured to function as 3-pole testers and work well in this situation.

However, things change once your house is connected to the power line. In this case, using a clamp-on ground resistance tester is the safer and more efficient option. Clamp-on testers avoid the need to disconnect any wires, making the testing process quicker and less risky.

Understanding Lead Length Requirements

If you decide to use a 3-pole or 4-pole tester, there’s an important factor to consider: the distance required for the auxiliary grounding rods. These temporary electrodes are placed around the grounding rod you’re testing to complete the measurement circuit.

The distance needed between these auxiliary rods and your grounding rod depends on the specific test method you’re using and the depth of your grounding rod. For example, a Fall-of-Potential test on a single grounding rod driven 8 feet deep might require the auxiliary rods to be placed at least 80 to 100 feet away. The more grounding rods you have on your property, the farther apart these auxiliary rods will need to be positioned.

Selecting the Right Lead Length for Your Needs

To simplify the testing process, consider purchasing a ground resistance test kit. These kits typically include the tester itself, the auxiliary electrodes, and the connecting leads. Lead lengths come in various options, commonly 150 feet, 300 feet, and 500 feet.

Here’s a pro tip for choosing the right lead length: always opt for a kit with leads that are longer than you think you’ll immediately need. If you anticipate needing 150 feet of lead for your current situation, a kit with 300-foot leads provides valuable extra reach. This additional length can be helpful for future measurements or if you encounter any unexpected challenges during setup. For larger properties with multiple grounding rods or complex grounding grids, a kit with 500-foot leads might be the best choice to ensure you have enough reach to perform the test properly.

Q. Does the test site have high soil resistivity and/or requires long test leads?

Selecting a ground resistance tester goes beyond just the type (3-pole vs clamp-on). Two additional factors can influence your choice: soil resistivity and the distances required for Fall-of-Potential testing.

High Soil Resistivity and Test Current:

Soil resistivity refers to how well the soil conducts electricity. In areas with high soil resistivity, the auxiliary electrodes used in Fall-of-Potential tests may have high contact resistance. This can be an issue for some lower-cost testers that provide only milliamp (mA) range test currents. These low currents may struggle to overcome the high contact resistance, leading to inaccurate measurements.

If you anticipate high soil resistivity, consider a tester with a higher injection current capability, typically reaching several hundred mA. This higher current helps overcome the increased contact resistance and ensures accurate measurements.

Long Fall-of-Potential Test Distances and Current:

Fall-of-Potential testing requires placing auxiliary rods a certain distance away from the grounding rod being tested. If your test setup requires unusually long distances between the grounding rod and auxiliary rods, a higher injection current may also be beneficial. This helps compensate for the increased lead resistance that comes with longer lead lengths.

Clamp-on Testers: The Advantage of No Auxiliary Rods

Clamp-on ground resistance testers offer a significant advantage: they don’t require any auxiliary rods or leads. This eliminates the need for extensive setup and avoids the challenges associated with high contact resistance in auxiliary electrodes. Furthermore, clamp-on testers allow for testing without taking the grounding system out of service, making them a convenient and efficient option.

Q. Is electromagnetic interference (EMI) present?

EMI and Ground Resistance Testing: Finding the Right Tool

Electromagnetic interference (EMI) can throw a wrench into your ground resistance testing. EMI can cause erratic or inaccurate readings, especially at lower test frequencies like the commonly used 128Hz. Here’s how to choose a tester that tackles EMI effectively:

  • Automatic Test Frequency Selection: Some testers offer a valuable feature: automatic test frequency selection. These instruments can intelligently scan for the “cleanest” available frequency to use during the test. This helps minimize the impact of EMI and ensures a more reliable measurement.

  • Clamp-on Testers for EMI-Prone Environments: Clamp-on ground resistance testers are generally less susceptible to EMI because they typically operate at higher frequencies. This inherent advantage makes them a good choice for environments with significant EMI. Additionally, some newer clamp-on models from AEMC even offer user-selectable test frequencies, providing even greater flexibility in tackling EMI challenges.

Important Note: Lower Frequencies in Specific Situations

It’s important to remember that while higher frequencies are often better for combating EMI, there can be exceptions. In some environments with high inductive loads, lower test frequencies might actually produce more reliable results.

Consulting a grounding expert can help you determine the optimal test frequency for your specific situation. They can help you navigate potential EMI issues and ensure you get the most accurate measurements possible.

Q. How will you use the measurement data?

DataView® Ground Tester Resistance vs Frequency report (above, left) and Model 6417 Android™ app (above, right)

The type of ground resistance tester you choose can also depend on how you plan to use the data you collect. If you intend to save, analyze, and share your test results, then data storage and report generation become important features to consider.

Many newer and more advanced testers, including both 3/4-pole and clamp-on models, offer built-in data storage capabilities. These instruments can store test results in their internal memory, allowing you to easily download and analyze the data later.

Here’s how this data storage can benefit you:

  • Detailed Analysis: By downloading the data to a computer, you can use specialized software to perform in-depth analysis of your test results. This software can generate charts, graphs, and reports, providing valuable insights into your grounding system’s health.

  • Mobile Convenience: Many testers also offer mobile app connectivity. This allows you to download test data directly to your smartphone or tablet, where you can analyze it using dedicated apps. An added advantage of mobile apps is the ability to instantly share your test results as an email or text message – a great feature for contractors who need to provide immediate reports to customers.

  • Long-Term Record Keeping: Storing your test data electronically allows you to maintain a long-term record of your grounding system’s performance. This historical data can be helpful for future maintenance and troubleshooting, providing valuable insights into how your grounding system performs over time.

Q. Do you need to test the bonding of grounding system components?

For complex grounding systems with multiple components like a ground mat or grid, you’ll need to go beyond just measuring resistance. A crucial next step is testing the continuity of the bonding connections between the various elements in the system. This continuity test is typically performed using DC voltage and current.

Many ground resistance testers can handle this task, offering test currents up to a few hundred milliamps. However, for an even more comprehensive test, consider using a micro-ohmmeter. This instrument’s key advantage is its ability to supply much higher test currents, reaching up to 200 amps. These high currents can expose potential problems in your grounding system that might not be apparent with the lower milliamp-range currents used in standard ground resistance testers. By using a micro-ohmmeter, you can ensure a more thorough and reliable evaluation of your complex grounding system’s health.

Reach out to us today to learn more or request a free quote at 800-353-3411 or [email protected].
