SK-4500-TC Handheld Cable and Antenna Analyzer

The SK-4500-TC provides critical coverage with a wide frequency range from 1 MHz to 4.5 GHz.

Discontinuities can be a real problem and cause significant reflections by damaged cables, loose or improperly installed connectors, and environmental factors. With Bird’s DTF (Distance to Fault) mode, SiteHawk finds the exact location of the problem “in true distance units”!

Eliminate wasted time swapping out components until you determine the issue. Save critical time, components, and money by correctly identifying issues the first time to efficiently direct vital resources to implement solutions.

Manufacturer	Bird Technologies

Categories: Analyzers, Rent Analyzers

RENT THIS ITEM

Daily, Weekly, and Monthly rates are available on select items.

Description
Reviews (0)

Product Overview: SK-4500-TC Handheld Cable and Antenna Analyzer

PRODUCT FEATURES

Test RF cables and antennas at the frequency of operation.
Locate RF cable, connector and antenna problems at the source.
FDR (Frequency Domain Reflectometry) measurement method results in a highly reliable assessment of the health of critical components in your system; ultimately providing a “heads-up” before a failure occurs.
Fault location or DTF mode plots VSWR or Return Loss levels at each distance point along the cable and antenna system length.
Cable Loss function measures insertion loss of the cable system over a given frequency range.
OTG USB communication port for connection to Bird power sensors, storage devices and battery charging.

APPLICATIONS

Cellular Networks 3G, 5G (2.4, 4.2 GHz & 600, 850 MHz)
PCS/DCS, CDMA, GSM and LTE Protocols
Broadcast
Paging
Government
Tactical Military
Microwave
Public Safety
Trunking, TETRA
Network Coverage WLAN, WLL (802.11)

SiteHawk Videos:

Note:
GPS Display & Logging features are compatible with SiteHawk model serial numbers 4006 and higher only! (Please see the installation procedure included in the GPS Activation zip file located in the Downloads section below.)
